Diameter:
Material:
Slot:
End Connection:
thickness:
Galvanized Water Well Bridge Slotted Screen is a type of well screen with vertical slots that are formed by protruding "bridges” that are pushed outward from the well casing.
Technical Data of Galvanized Water Well Bridge Slotted Screen
|
ND (mm) |
146 |
159 |
219 |
273 |
325 |
377 |
426 |
529 |
||||||||||||
|
ID (mm) |
130 |
140 |
138 |
200 |
198 |
254 |
250 |
246 |
305 |
300 |
297 |
357 |
350 |
346 |
406 |
400 |
398 |
502 |
500 |
498 |
|
WT (mm) |
5 |
5 |
6 |
5 |
6 |
5 |
6 |
8 |
5 |
6 |
8 |
5 |
6 |
8 |
5 |
6 |
8 |
6 |
7 |
8 |
|
OD (mm) |
146 |
160 |
162 |
220 |
226 |
274 |
278 |
278 |
325 |
328 |
329 |
377 |
378 |
379 |
426 |
428 |
432 |
529 |
530 |
531 |
