Introduction of Stainless Steel 316L Johnson Screen Nozzle Filters,
Stainless Steel 316L Johnson Screen Nozzle Filters is a kind of water filter nozzle. It is made of Johnson wedge wire screen. The filtering slot is V shape. The special structure makes the filter nozzle a high filtering efficiancy .
Material: 316L wedge wire screen 18S 1.52*2.54mm
Slot size: 0.7mm
Fitlering Open Area: 41%
|
Filter nozzle Name |
Stainless Steel 316L Johnson Screen Nozzle Filters |
|
Filter nozzle Code |
SS316TZW |
|
Main feature of Stainless Steel 316L Johnson Screen Nozzle Filters |
High strength; |
Structure Details
Stainless Steel 316L Johnson Screen Nozzle Filters - Filtering direction- FOTI
The filtration direction of this filter nozzle is from outside to inside, The wedge wire wrapped on the support rods continuously.
Stainless Steel 316L Johnson Screen Nozzle Filters Profile Wire
18S/ W1.52 *H2.54mm
Material: 316L
Shape: Wedge Wire
Stainless Steel 316L Johnson Screen Nozzle Filters Support Rod
Q25 / W2*H3mm
Matieral: SS304 /316L
Shape: Square
Feature
|
SS316 Stainless Steel Water Treatment Sand Filter Nozzle provides it with the following characteristics |
High mechanical strength |
|
Freestanding structure |
|
|
Absolute filtration threshold |
|
|
Continuous slots having openings down to 15 μm |
|
|
Increased open surface |
|
|
Anti-clogging surface |
Stainless Steel 316L Johnson Screen Nozzle Filters will be used for water treatment .
Anticipate cooperation with you.
Different OD, slot size, material, filtering direction, Unit Length , and many other factors will influence on the price and production.
