Advantages of water well johnson filter screen pipe,
1. Screens with high open area are more suitable for the construction of high-quality water wells, oil wells and gas wells.
2. Low cost operation Screens with high open area shall favor groundwater infiltration. Abundant water shall reduce the water level’s down, thus to save energy consumption.
3. Reduce the abrasion of the pump
Under the same condition, high open area can make the speed of groundwater’s entering into the screen much slower than any other filtration apparatus, which will avoid sand’s entering into screen because of high pressure, thus reduce the abrasion of the pump.
4. Extend the life span of wells
Comparatively, groundwater’s entering into screen with higher open area is much easier than the entering into lower open area screen. The slow water flow shall extend the life span of wells.
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------
If you wana the price of water well johnson filter screen pipe, pls allow me to know the questions as follow:
1.What the diameter of well strainer do you need?Standard diameter:2inch 4inch 6inch 8inch 10inch 12inch ect,our factory can make the diamater of 25-1200mm
2.Would you like to tell me the specification of V wire?Engineer recemand:1.5*2mm 2*3mm 2.2*3.5mm 3*5mm 3.2*6mm, It's up to you at last.
3.Pls tell me the slot size,the size usually is 0.1-6.0mm.
4.I hope you can tell me the depth of well and which aspect do you plan to be used in?
5.How many meters do you need?the more you want,the price will be cheaper.
Our engineer will recommend you the most suitable specification according our 20 years experience.
Quick Details of water well johnson filter screen pipe,
Place of Origin: |
Henan, China (Mainland) |
Brand Name: |
TIANZHIWO |
Model Number: |
8inch |
Usage: |
Liquid Filter Solid Filter |
Type: |
Filter Cylinder |
Advantage |
from direct factory |
Hole Shape: |
Round |
Filter Rating: |
10%-30% |
Thickness: |
3-12mm |
Length: |
up to 6m |
Width: |
219mm |
OD: |
25-1200mm |
slot size: |
0.1-6.0mm |
End connection: |
threaded coupling,flanged,plain beveled end |
Surface treatmrnt: |
Galvanized or painting |
Material:: |
low carbon steel, stainless steel |
Certification:: |
ISO/CE/SGS/CIQ |
V WIRE: |
1.5*2-3.5*6.8mm |
Packaging & Delivery
Packaging Details: |
bulk or bundle or container or as customer require |
Delivery Detail: |
15-20days after down payment |
water well johnson filter screen pipe is widely used in beverage/ beer filtration, papermaking industry, industrial waste water treatment, oil, water desalination, etc.
