water filter pipe screens for water well construstion
Diameter:
Material:
Slot:
End Connection:
thickness:
Product Categories
Water well screens
Johnson type screen
Bridge slotted screen
Pre-pack well screen
Stainless steel well screen
Oil well screen
Perforated Pipe
Slotted Liners
Water treatment & Filtration
Wedge wire screen
Industry Filters
Resin Traps
Strainer
Sieve Plate
Filter Nozzle
Well Casing & Accessories
Spiral steel pipe
API casing
Seamless casing pipe
Centralizers
Pup Joints
Reducer
Coupling
Successful Cases
Perforated oil well screen
Johnson wedge wire screen cartridge for industry filtration
Cage type stainless steel wire wrap water well pipe
Contact Us
overseas@xxfilter.com
+86-373-2515856
Add: Filter Industrial Zone,Beihuan Road,Muye District,Xinxiang City,Henan P.R.China
Introduction
Technical Data
Application
Inquiry
Introduction
Screen Size
Inside Diameter
Outside Diameter
OD of Female
Threaded End
in
mm
In
mm
in
mm
In
mm
2
51
2
51
25/8
67
23/4
70
3
76
3
76
35/8
92
33/4
95
4
102
4
102
45/8
117
43/4
121
5
127
5
127
55/8
143
53/4
146
6
152
6
152
65/8
168
7
178
8
203
8
203
85/8
219
91/4
235
10
254
10
254
103/4
273
113/8
289
12
305
12
305
123/4
324
133/8
340
14
356
131/8
333
14
356
—
—
16
406
15
381
16
406
—
—
20
508
18 3/4
476
20
508
—
—
Technical Data
Specification (Profile wire):
Width(mm): 1.50 1.80 2.30 3.00 3.30 3.70
Height(mm): 2.20 2.50 2.70 3.60 4.30 4.70 5.60 6.30
Specification (support rods):
Width(mm): 2.30 3.00 3.30 3.70
Height(mm): 2.70 3.60 4.70 5.60 6.30
Round: From 2.50mm to 6.0mm
Note: other wires and rods available upon request
Slot size
0.10, 0.15, 0.20, 0.25, 0.30…… 6.00mm also achieved upon request.
Material:
Low carton, low carton galvanized steel (LCG), stainless steel (304,316 etc.)
Length
Lengths up to 6 meters.
Diameter
ranging from 25mm to 800mm.
End connection
Plain beveled ends for butt welding or threaded
Application
Opening area calculate
Slot Size * 100
Open Area (%) = ---------------------------------
Slot size + Wire width
