Specification (Profile wire):	Width(mm): 1.50 1.80 2.30 3.00 3.30 3.70 Height(mm): 2.20 2.50 2.70 3.60 4.30 4.70 5.60 6.30
Specification (support rods):	Width(mm): 2.30 3.00 3.30 3.70  Height(mm): 2.70 3.60 4.70 5.60 6.30 Round: From 2.50mm to 6.0mm
Note: other wires and rods available upon request
Slot size	0.10, 0.15, 0.20, 0.25, 0.30…… 6.00mm also achieved upon request.
Material:	Low carton, low carton galvanized steel (LCG), stainless steel (304,316 etc.)
Length	Lengths up to 6 meters.
Diameter	ranging from 25mm to 800mm.
End connection	Plain beveled ends for butt welding or threaded

SIZE (inch)	O.D (mm)	SLOT (inch)	LENGTH (m)	Collapse Strength (psi)	Tensile Weight (ton)	Wire siz (mm)	RODS (mm)
4	117	0.040	3	395	6	2.2*3.0	3.8mm/22
4	114.3	0.040	3	395	6	2.3*3.0	3.8mm/22
6	168.3	0.040	3	252	8	2.3*3.5	3.8mm/32
8	219.1	0.010	3	399	10.5	3.0*5.0	3.8mm/48
8	219.1	0.020	3	370	10.5	3.0*5.0	3.8mm/48
8	219.1	0.040	3	323	10.5	3.0*5.0	3.8mm/48
10	273.1	0.010	3	206	11	3.0*5.0	3.8mm/50
10	273.1	0.020	3	191	11	3.0*5.0	3.8mm/50
10	273.1	0.040	3	167	11	3.0*5.0	3.8mm/50

Professional factory:
We are manufacturer, specializing in manufacturing filters, competitive price with good quality. The deadline usually is 30 days

Sample:
Free samples are available for your requirement,but the shipment charge usually paid by your side, the fee of it will be rebound when we have formal order.
Test reports of filters are available with each delivery.
Rapid response to your needs: We will answer within 24 hours.
Welcome to contact with us if you have any problems.
We are looking forward to cooperating with you.
