Materials : 304, 302, 304L, 316, 316L stainless steel wire, or galvanized steel
wire.O.D : 1 inch, 3inch, 4inch, 6inch, 8inch, 10inch, 12inch.
the slot : 0.1mm-45mmthe wire :2.0mm*30.mm, 3.0mm*4.6mm, 3.0mm*5.0mmthe rods:3.8mm/22, 3.8mm/32, 3.8mm/48, 3.8mm/50
The rod can be round wire, triangular wire or trapezoid wire.
The warp is triangular wire (V-shaped wire).
Styles of connection: by welding or by threaded male/female coupling.
Standard length: 1m-5.85m
2.The profile wire wraps around internal array of longitudinal support rods.
Each intersecting point of these wires is fusion welded.
3.The profile wire wraps around the support rods over the full length of the screen creating
a continuous slot opening. So the screen can allow water and oil to enter the well freely.
4.it keeps the majority of the sand and gravel out of the well.
The length and the thickness are according to the customers' requirements.
Meanwhile ,our company can offer a whole set of service,such as the related process,
the solution of the related technology and so on
1.The strainer is a kind of filtered water tubing with the perforation .
2.it can use with the deep well pump, dive the water pump, also may use in the water-treating equipment,
the environmental protection, the sea water transforms into the industrial water and life use water desalination treatment,
running water treatment, water softening treatment, the petroleum industry:
3.The petroleum product terminal filters and the chemical acid, the alkali liquid filters,
the ethyl alcohol and so on the organic solution recycling filters.
If you are interested in our product, please contact us, and for more information.
