Diameter: Material: Slot: End Connection: thickness:
v-shape well screen pipe is made up of rods and warp. The rod can be round wire, triangular wire or trapezoid wire. The warp is triangular wire (V-shaped wire).
Specification of v-shape well screen pipe :
Width(mm): 1.5,2.0,2.3,2.5,3.0,3.3,3.7,4.0,4.5
Height(mm): 1.5,2.2,2.5,2.7,3.0,3.6,4.0,4.5,4.7,5.5
Round rods : diameter from 2.50mm to 6.0mm
Note: other wires and rods available upon request
Slot size(mm): 0.05,0.08,0.10,0.15,0.20,0.25,0.30,1.0,2.0,5.0... 45mm also achieved upon request.
Diameter(mm):27,50,100,200,500,1000.
Length: up to 6 meters.
End connection: Plain beveled ends for welding or threaded male &female coupling(spiral).
Other sizes available on request. Deep well construction specifications available on question.
Water well screens are designed for depths of 100 m, 200 m, 350 m & 600 m.
v-shape well screen pipe is used for oil and water exploiting.
